Controlador de velocidad de ventilador de motor con regulación de voltaje variable

Descripción

Notes: When measuring the output voltage when it is empty, it is a virtual voltage. It must be connected to a load of 20W or more to measure the correct output voltage. Input AC power, the output is also AC, not DC. The inductive load is 1/3 of the resistive load. The resistive load means that the inductive load such as a tungsten filament lamp or a heating wire is a series-excited motor, etc., and the circuit board electronic products are used with caution. This product is a metal case and must be grounded safely. Features: Adopts metal shell structure, high temperature resistance, flame retardant, not easy to rust Core chip adopts high power thyristor With adjustable knob for stepless voltage regulation No delay, anti-surge, anti-spike, RC absorption multiple protection With universal power socket and power supply light With heat dissipation port for fast heat dissipation Input Voltage: AC 220V Output Voltage: 30~220V (stepless adjustable) Max Power: 4000W （The maximum power is 4000w; the rated power is limited according to different products. The tungsten lamp is 4000w, the heating type is 3000w, the electric tool is 2000w, and the fan type is 1500w.） Rated Current: 9A Max. Current: 18A Package Contents: 1 * Voltage Regulator(UK Plug)
